Easy Installation, Diversified Application, High Accuracy, Assembly Flexibility
Features
Installation Site: Tilt roof
Roof Cladding: Suitable for most types of claddings
Mounting Angle: 0~60 degree
Wind Load: 130KM/H
Snow Load 1.4KN/m3
PV Modules: framed
Array Orientation: Horizontal or vertical
Module Size: Any
Support Rail: Stainless steel
Warranty: 10 years durability on materials
Life Time: 25 years
More elegant solution than hanger bolts or standoffs.
Compared to hanger bolts:
Drilling tile is not required
Tiles are not subject to cracking and failure over time due to normal flexure of hanger bolt.
Compared to standoffs:
Easier to install, do not require cutting tile or flashing in most instances.
Superior aesthetics.
Features:
Works with plain tile or flat tiles.
Slotted hole on top of hook gives good adjustable relative to rail.
Easy to install.
Installation:
Remove and trim tiles at installation point if necessary.
If tiles are trimmed, prepare and insert sheet metal flashing.
Place roof hook in desired position, drive supplied screws into rafter.
replac overlying tile.
Weight: 0.525kg.
Material: SS-304.
Packing: 1980pcs/pallet.
